Engine

Kubota D1505 (4 cylinder), Stage V

Engine power

26 hp / 19 kW

Fuel

Diesel

Service weight¹

2,400 kg

Lifting capacity

2,200 kg

Tipping load²

2,600 kg

Lifting height²

2,498 mm

Length without bucket

3,316 mm

Width on standard tires

1,100 mm

Driving mechanism

Hydrostatic 4 wheel drive with automotive control
8 tons planetary axles with 18.000 N pulling force.

Control

Drive back and forward through electrical switch

Differential lock

Limited slip on both axles

Driving hydraulics

84 ltr/min (350 bar)

Working hydraulics

42 ltr/min (210 bar)

Driving speed

0-10 km/h, 0-20 km/h

Parking brake

Drum brakes

Colour

GIANT yellow / GIANT grey / black

A

Wheelbase

1,695 mm

B

Total length (without bucket)

3,316 mm

C

Total length (with bucket)

4,085 mm

D

Length 3-point lifting arm

540 mm

E

Min. height 3-point hitch

253 mm

F

Max. height 3-point hitch

652 mm

G

Seat top height

1,341 mm

H

Max. height with ROPS/FOPS safetyroof

2,322 mm

I

Max. height with ROPS/FOPS cabin

2,345 mm

J

Height frontframe

1,492 mm

K

Dumping height

1,735 mm

L

Max. height pivot

2,498 mm

M

Max. height with bucket

3,070 mm

N

Rollback angle (on the ground)

42°

O

Rollback angle at max. lifting height

47°

P

Dumping angle (max.)

37°

Q

Loading angle (max.)

28°

R

Diameter standard tire

Ø850 mm

1A

Maximum radius external

3,045 mm

1B

Radius at the outer edge

2,623 mm

1C

Inside turning radius

1,523 mm

1D

Min. machine width

1,100 mm
