| Engine | Kubota V1505, Stage V |
| Engine power | 26 HP / 19 kW |
| Type | Diesel |
| Service weight1 | 2.350 kg |
| Lifting capacity | 2.200 kg |
| Tipping load2 | 2.260 kg |
| Lifting height2 | 2.450 mm |
| Length without bucket | 3.145 mm |
| Width on standard tires | 1.080 mm |
| Driving mechanism | Hydrostatic four wheel drive with automotive control 8 tons planetary axles (HD version) with 23.000 N pulling force. Limited slip on both axles. |
| Control | Drive back and forward through electrical switch |
| Differential lock | Axles with limited slip on both axles |
| Driving hydraulics | 65 ltr/min (360 bar) |
| Working hydraulics | 32 ltr/min (210 bar) |
| Driving speed | (0-10 km/h, 0-20 km/h) |
| Parking brake | Drum brakes |
| Colour | GIANT yellow / GIANT grey / black |
1 Measured with earthbucket
2 Measured on hinge point in straight position on standard tires
| A | Wheelbase | 1.580 mm |
| B | Total length (without bucket) | 3.145 mm |
| C | Total length (with bucket) | 3.830 mm |
| D | Length 3-point hitch | 622 mm |
| E | 3-Point hitch in lowest position | 134 mm |
| F | 3-Point hitch in highest position | 797 mm |
| G | Seat height | 1.256 mm |
| H | Max. height with ROPS/FOPS safety roof | 2.300 mm |
| I | Max. height with ROPS/FOPS cabin | 2.284 mm |
| J | Height front frame | 1.250 mm |
| K | Max. dumping height | 1.680 mm |
| L | Lifting height | 2.450 mm |
| M | Height with bucket | 3.040 mm |
| N | Rollback angle on the ground | 41° |
| O | Rollback angle at max. lifting height | 46° |
| P | Max. angle for bucket emptying | 37° |
| Q | Drive-up angle | 29° |
| R | Outer size of tires | ø760 mm |
| 1D | Width on standard tyres | 1.080 mm |
| 1A | Turning radius with bucket | 2.650 mm |
| 1B | Turning radius on outer edge | 2.342 mm |
| 1C | Inner turning radius | 1.230 mm |
Dimensions are measured on standard tires
 |
