Compact powerhouses - as the A-series can be described - are characterized by very compact construction, allowing easy maneuverability in tight areas. With a tipping load of 1,000 kg, the G1100 can almost lift its own weight!

Standard version

Hitch: GIANT Compact (Mechanically)
ROPS / FOPS safety roof
Double acting hydraulic valve on lifting arm (mechanical)
Floating position on lifting cylinder(s)
Luxury seat with safety belt, armrest and extended backrest
Main switch
Oil cooler
Lifting eyes

Engine	Kubota D722 (3 cylinder)
Engine power	20 HP / 15 kW
Fuel	Diesel
Service weight¹	1,100 kg
Lifting capacity	1,100 kg
Tipping load²	1,000 kg
Lifting height²	2,170 mm
Length without bucket	2,200 mm
Width on standard tires	920 mm
Driving mechanism	Hydrostatic 4 wheel drive with automotive control by 4 heavy Poclain wheel engines
Control	Drive back- and forward through electrical switch
Differential lock	Electric controlled slip differential
Driving hydraulics	65 ltr/min (350 bar)
Working hydraulics	28 ltr/min (150 bar)
Driving speed	0-15 km/h
Parking brake	Hydraulic multidisk brake
Colour	GIANT yellow / GIANT grey / black

¹ Measured with earth bucket

² Measured on hinge point in a straight position on standard tires

Dimensions

undefined

A	Wheelbase	1,205 mm
B	Total length (without bucket)	2,211 mm
C	Total length (with bucket)	2,911 mm
D	Length 3-point lifting arm	--
E	Min. height 3-point hitch	--
F	Max. height 3-point hitch	--
G	Seat top height	1,020 mm
H	Max. height with ROPS/FOPS safetyroof	2,060 mm
I	Max. height with ROPS/FOPS cabin	--
J	Height frontframe	1,380 mm
K	Dumping height	1,408 mm
L	Max. height pivot	2,170 mm
M	Max. height with bucket	2,976 mm
N	Rollback angle (on the ground)	43°
O	Rollback angle at max. lifting height	45°
P	Dumping angle (max.)	46°
Q	Loading angle (max.)	34°
R	Diameter standard tire	ø570 mm
1A	Maximum radius external	2,225 mm
1B	Radius at the outer edge	1,967 mm
1C	Inside turning radius	978 mm
1D	Min. machine width	920 mm

Dimensions are measured on standard tires

Tires


23x8.5-12 AS	23x8.50-12 SKID	23x8.50-12 ÇİM TİPİ
(Standart)


23x10.50-12 AS	23x10.50-12 ÇİM TİPİ	24X13-12 ÇİM TİPİ

İsteğe bağlı seçenekler


ROPS / FOPS standart emniyet tavanı	Metal çamurluklar	Denge ağırlıklı veya ağırlıksız çekme topuzu


Hızlı çoklu hidrolik giriş	El gazı	Manuel devir kontrolü
