GIANT GT5048
Telehandlers
GIANT GT5048
GIANT GT5048

GIANT’s GT5048 Series range is one of the most compact and versatile machines it offers, designed to manoeuvre in tight spaces and on rough terrains, while its extendable lifting arm can reach an astonishing height of 4.8 meters as standard model.

The GT5048 is equipped with a proportional load moment protection combining safety with optimum performance.

This GIANT GT5048 is powered by a Stage V 50 hp engine, while in addition it offers many optional features.


Standard version

  • Hitch: GIANT Standard (Hydraulically)
  • ROPS / FOPS safety roof, with a window front and right, and front wiper
  • CANBUS system
  • Double acting hydraulic valve at the front (mechanical)
  • Luxury seat with safety belt, armrest, and extended backrest
  • Proportional Load Moment Protection (EN 15000)
  • 1 working light on the lifting arm
  • Rupture protection
  • Main switch
  • Cyclone filter
  • Oil cooler
  • Towing hook / Conen pin

Specifications

Service weight

1

2950

Tipping Load

2

2490

Lifting height

3

4800

Length without bucket

3135

Machine height

4

1970

Width on standard tires

1600

Standard tires

10.00/75-15.3 AS

Travel Speed

0-10 km/h <<>> 0-25 km/h  (met rijautomaat)

Engine

Kubota D1803 CR (STAGE V)

Cylinders

3

Engine power

50 hp

Engine power

(kW)36

Fuel tank capacity

38

Fuel tank capacity

38 l

Oil tank capacity

75 l

TypeHydrostatic

 Four wheel drive

Transmission

Automotive control

Differential

Four-wheel steering

Final drive

8 tons axles, heavy planetary end drive

Pulling force

22600

Driving hydraulics

84 l/min (350 bar)

Working hydraulics

51 l/min (230 bar)

Parking brake

Disk brakes

1

Measured with earth bucket

2

Measured with counterweight and driver ± kg

3

Measured with counterweight and driver ± kg

4-3

Measured on standard tyres with safety roof
